Type

G28-G33-G38-G47-G55-G72-G90

Flange

BKT, SAE-A standard or SAE-B (option)

Connections

GAS or SAE 3000/6000 flange

Installation

Free

Shaft rotation

Clockwise viewed at the shaft end

Shaft speed

100 - 3600rpm

Flows

From 0 to 800L/min (1500rpm)

Outlet pressure

Continuous:270 bar; Max:300 bar

Inlet pressure

From 0.7 to 2bar（10bar option)

Fluids

Mineral oil HLP and HLVP

Ecologic fluids HETG-HEPG-HEE

HFA oil-water emulsion - oil minimum 5%

HFB water-oil emulsion < 40%

HFC water-glycol - water max 35 to 55%

HFDR phosphate ester

Lubrication high viscosity oil

Special synthetic fluid: MIL-H、SKYDROL; special on request

Viscosity

Recommend： from 4 to 2000cst

Working temperature

From -20 to +80℃

Filtration

Inlet: 100µm Outlet:10-25µm

Seal

NBR、FPM、EPDM

Noise level

From 54 to 68 dB (A) at 2750rpm base on IS04412

Pump body

Extruded aluminum alloy, cast iron

Rotors

Hardened steel
